Home / Electronic Turbo Actuator
product review overlay image
Volkswagen Phaeton 5.0 TDI Electronic Turbo Actuator G-22 755297-5004S Garrett
Volkswagen Phaeton 5.0 TDI Electronic Turbo Actuator G-22 755297-5004S Garrett
Volkswagen Phaeton 5.0 TDI Electronic Turbo Actuator G-22 755297-5004S Garrett
Volkswagen Phaeton 5.0 TDI Electronic Turbo Actuator G-22 755297-5004S Garrett
Volkswagen Phaeton 5.0 TDI Electronic Turbo Actuator G-22 755297-5004S Garrett

Product Description

Volkswagen Phaeton 5.0 TDI Electronic Turbo Actuator G-22 755297-5004S Garrett

Hella Number:
G-22 730314 6NW009228

Turbo Part Number:
755299-5007S ， 755299-0006 ， 755299-0003/5 ， 755299-0001 ， 742809-0005 ， 723213-0003 ， 723213-0001 ， 755299 , 723213

Turbo OEM Number:
07Z145701T , 07Z145701TX , 07Z145701TV , 07Z145701Q , 07Z145873H , 07Z145907H


Fit For:
Turbo actuator for Volkswagen Touareg V10 TDI Links 230 Kw - 313 HP AYH Links 2002-2009



Fast Shipping!
From UK Stock with Fast Delivery

Please Check Part Number Before Ordering.



2 Years Parts Only Guarantee with Unlimited Mileage

Exchange Reconditioned Replacement Turbo Actuator from Stock

Turbo Actuator Repairs Includes the Worm Gear, Motor, and Electronics Pre-Calibrated



Actuator Deposit
We Need £100 Deposit Before Positing Actuator
as This Is an Exchange Part, So We Need Your Old Used Faulty Actuator Back
£100 Deposit Will Be Refunded When You Send Your Old Actuator to Us
or
you can send your part to us first ( then no deposit needed )




Hella Actuator Part Numbers G-108 & G-277 & G-33 etc,,,,

Can Be Found on the Aluminium Side of the Actuator or Send Us Your Car Reg Number and We Will Check If This Is Right for Your Car


Electronic Turbo Actuator Problems Can Be Any or All of the Following

Turbo Actuators Have Been Known for Cutting Out and Losing Power When Hot and Cold, with the Engine Management / Glow Plug Light or Coil Light Coming on the Dashboard, at This Point the Car Will Go into Limp Mode / Limp Home Mode.

Also, Automatic Gearbox Problem Problems.

Loss of Power Under Acceleration, Actuator Arm Not Moving at All or When Hot, No Boost, Loss of Power

This Will Start Out by Happening Sometimes and Not at Other Times

But Eventually Your Car Will Be Stuck in Limp Mode, Until the Turbo Actuator Has Been Repaired or replaced


Before Fitting Our Actuator

Please Check the Actuator Rod Which Goes into the Turbo and Makes Sure the

Turbo Vanes Are Not Sticking to Stuck

How to Check If the Turbo Vanes with the Engine Warm or Hot Take the Cir-clip Off the Arm on the Actuator Side So the Actuator Is Now Disconnected from the Actuator Rod Then Push and Pull the Actuator Rod Arm Very Gently, to See If It Moves Freely or Sticks at Any Point. You Will Probably Find It Sticks and Does Not Move the Full Range or Freely, Normally the Vanes Will Stick or Go Tight at Either End, Especially When Hot.




Domestic postage:
Royal Mail Tracked 24 (1 to 2 working days)                         Free
Royal Mail Special Delivery(TM) 1:00 pm (1 working day)  £9.60  (orders before 2:00 pm)



Specifications

MPN
6NW009228
Type
TURBO ACTUATOR
UPC
G-22
EAN
755299-0003
Brand
GARRETT
Condition
Refurbished
Product Code
EAG-22-V
Weight
0.5kg

Customer reviews

No reviews left yet
Write A Review

Volkswagen Phaeton 5.0 TDI Electronic Turbo Actuator G-22 755297-5004S Garrett

Hella Number:
G-22 730314 6NW009228

Turbo Part Number:
755299-5007S ， 755299-0006 ， 755299-0003/5 ， 755299-0001 ， 742809-0005 ， 723213-0003 ， 723213-0001 ， 755299 , 723213

Turbo OEM Number:
07Z145701T , 07Z145701TX , 07Z145701TV , 07Z145701Q , 07Z145873H , 07Z145907H


Fit For:
Turbo actuator for Volkswagen Touareg V10 TDI Links 230 Kw - 313 HP AYH Links 2002-2009



Fast Shipping!
From UK Stock with Fast Delivery

Please Check Part Number Before Ordering.



2 Years Parts Only Guarantee with Unlimited Mileage

Exchange Reconditioned Replacement Turbo Actuator from Stock

Turbo Actuator Repairs Includes the Worm Gear, Motor, and Electronics Pre-Calibrated



Actuator Deposit
We Need £100 Deposit Before Positing Actuator
as This Is an Exchange Part, So We Need Your Old Used Faulty Actuator Back
£100 Deposit Will Be Refunded When You Send Your Old Actuator to Us
or
you can send your part to us first ( then no deposit needed )




Hella Actuator Part Numbers G-108 & G-277 & G-33 etc,,,,

Can Be Found on the Aluminium Side of the Actuator or Send Us Your Car Reg Number and We Will Check If This Is Right for Your Car


Electronic Turbo Actuator Problems Can Be Any or All of the Following

Turbo Actuators Have Been Known for Cutting Out and Losing Power When Hot and Cold, with the Engine Management / Glow Plug Light or Coil Light Coming on the Dashboard, at This Point the Car Will Go into Limp Mode / Limp Home Mode.

Also, Automatic Gearbox Problem Problems.

Loss of Power Under Acceleration, Actuator Arm Not Moving at All or When Hot, No Boost, Loss of Power

This Will Start Out by Happening Sometimes and Not at Other Times

But Eventually Your Car Will Be Stuck in Limp Mode, Until the Turbo Actuator Has Been Repaired or replaced


Before Fitting Our Actuator

Please Check the Actuator Rod Which Goes into the Turbo and Makes Sure the

Turbo Vanes Are Not Sticking to Stuck

How to Check If the Turbo Vanes with the Engine Warm or Hot Take the Cir-clip Off the Arm on the Actuator Side So the Actuator Is Now Disconnected from the Actuator Rod Then Push and Pull the Actuator Rod Arm Very Gently, to See If It Moves Freely or Sticks at Any Point. You Will Probably Find It Sticks and Does Not Move the Full Range or Freely, Normally the Vanes Will Stick or Go Tight at Either End, Especially When Hot.




Domestic postage:
Royal Mail Tracked 24 (1 to 2 working days)                         Free
Royal Mail Special Delivery(TM) 1:00 pm (1 working day)  £9.60  (orders before 2:00 pm)


No reviews left yet
Write A Review

MPN
6NW009228
Type
TURBO ACTUATOR
UPC
G-22
EAN
755299-0003
Brand
GARRETT
Condition
Refurbished
Product Code
EAG-22-V
Weight
0.5kg
